IBM 74Y4064 User Manual

Form factor
Short
Cables
For information about the cables, see “Cables” on page 206.
Attributes provided
• NPIV capability is supported through VIOS.
• Requires a PCI Express generation-2 x8 slot for all four ports to operate at full speed.
Cables
Use multimode ber optic cables with shortwave lasers that adhere to the following specications:
• OM3: Multimode 50/125 micron ber, 2000 MHz x km bandwidth
• OM2: Multimode 50/125 micron ber, 500 MHz x km bandwidth
• OM1: Multimode 62.5/125 micron ber, 200 MHz x km bandwidth
Because core sizes are different, OM1 cables can only be connected to other OM1 cables. For best
results, OM2 cables should not be connected to OM3 cables. However, if an OM2 cable is connected to an
OM3 cable, the characteristics of the OM2 cable apply to the entire length of the cables. The following
table shows the supported distances for the different ber optic cable types at different link speeds.
Table 43. Supported distances for multimode ber optic cables
Header Cable Type and Distance
Rate OM1 OM2 OM3
2.125 Gbps 0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 300
meters (1.64 feet to
984.25 feet)
0.5 meters to 500
meters (1.64 feet to
1640.41 feet)
4.25 Gbps 0.5 meters to 70 meters
(1.64 feet to 229.65
feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
0.5 meters to 380
meters (1.64 feet to
1246.71 feet)
8.5 Gbps 0.5 meters to 21 meters
(1.64 feet to 68.89 feet)
0.5 meters to 50 meters
(1.64 feet to 164.04
feet)
0.5 meters to 150
meters (1.64 feet to
492.12 feet)
Operating system or partition requirements
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether any prerequisites must be met for this feature and attaching
devices. For information about operating system and partition requirements, see one of the following
topics:
• The latest version of enabling libraries and utilities can be downloaded from Fix Central (http://
www.ibm.com/support/xcentral/).
• Power Systems Prerequisites (http://www14.software.ibm.com/support/customercare/iprt/home).
• IBM SSIC (System Storage Interoperation Center) (http://www-03.ibm.com/systems/support/storage/
ssic/interoperability.wss).
• The latest version of the device driver or IBM Power RAID adapter utilities (iprutils) can be downloaded
from the IBM Service and Productivity Tools website (http://www14.software.ibm.com/webapp/
set2/sas/f/lopdiags/home.html).
• For support details, see the Linux Alert website (http://www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.html).
206
Power Systems: Managing PCIe adapters
