010 (continued)
DOES THE INSTALLED DEVICES LIST CORRECTLY IDENTIFY THE
DEVICES INSTALLED IN THE SYSTEM UNIT?
Note: If necessary, remove the cover and visually compare the devices
installed in the system unit to those shown in the installed devices
list.
Yes No
011
– Press N, then press Enter.
Note: A 199 error at this point indicates you answered “No” to the
question above. Disregard the error.
– Select 0 to add items. Press Enter.
– Select the number of the item you want to add and then press
Enter.
– Press Y, then press Enter.
– Select the 0 (RUN TESTS ONE TIME) option, then press Enter.
– Select only the item that you added to test, then press Enter.
Note: The Installed Devices list shows only those devices
supported by the Advanced Diagnostics diskette and only
factory-installed devices for the model you are servicing. If a
device is missing from the list and is not factory installed,
refer to the service manual provided for that device. (Refer
to the Appendix, “Model/Monitor Configurations and FRU
Part Numbers” on page A-1 to determine the
factory-installed devices in the model you are servicing.)
If a factory-installed drive device or adapter card is not listed
in the Installed Devices list, go to either “Diagnostics for
Factory-Installed Drive Devices Not Supported by Advanced
Diagnostics” on page 2-40 or “Diagnostics for
Factory-Installed Riser Card, Sound Card, or Adapter Cards
Not Supported by Advanced Diagnostics” on page 2-43.
WERE YOU ABLE TO CORRECT THE INSTALLED DEVICES LIST
TO MATCH THE DEVICES INSTALLED IN THE SYSTEM UNIT,
WITHOUT RECEIVING AN ERROR CODE OR MESSAGE?
Yes No
012
(Step 012 continues)
Check Procedures 2-7
To Next Page
