(continued)
Supply” on page 2-26 and “System Board Layout—Type I-1”
on page 5-2 and “System Board Layout—Type I-2” on
page 5-5.
– Run the Advanced Diagnostics again to ensure there are no
other system failures. If you return to this point a second
time, go to “Index of Symptoms, Messages, Error Codes, or
Beeps” on page 2-10.
009
– Run the System Checkout test again to ensure the system is
operating normally.
010
– Press Y, then press Enter. Follow the instructions on the screen.
– Select the number of times to run the test.
– Press Enter.
– Select the option you want to test, or press Enter to select all options.
Note: If you receive a 199 error, or if you have an undetermined
problem, run all tests.
DOES THE DIAGNOSTIC TEST FINISH WITHOUT ERROR CODES?
Yes No
011
– If the last test stops and you cannot continue, first make sure all
switches, power connectors, cables, and jumpers are set and
seated correctly and show the correct voltages. Then replace the
last device tested.
– Make note of any messages, error codes, beeps, or new symptoms.
Go to “Index of Symptoms, Messages, Error Codes, or Beeps” on
page 2-10.
012
– The Advanced Diagnostics did not detect a failure. If the system still
displays a failure:
Check all adapter card jumper settings.
Check all adapter card switch settings.
Check all adapter card cables and connectors for proper installation.
Check all power connectors for correct voltages. See “Power Supply”
on page 2-26 and “System Board Layout—Type I-1” on page 5-2
and “System Board Layout—Type I-2” on page 5-5.
2-36
