Table 8. IBM Flex System p260 Compute Node parts (continued)
Index Description
CRU part number
FRU part
number
Failing
function
code (FFC)
(Tier 1) (Tier 2)
1457-7F2 base system-board and chassis assembly:
v 3.6 GHz, 16-core system board (CCIN A898)
v 4.1 GHz, 16-core system board (CCIN A897)
v 00E1832
v 00E1825
Various
FFCs. See
“Failing
function
codes” on
page 446
1 IBM Flex System 2-port QDR InfiniBand adapter 90Y3461 2627
1 IBM Flex System 2-port 8 Gb Fibre Channel adapter 69Y1941 2E16
1 IBM Flex System 4-port 10 Gb Ethernet adapter 81Y3125 2E37
1 IBM Flex System 4-port 1 Gb Ethernet adapter 49Y7902 2E3D
1 IBM Flex System 8-port 10 Gb converged adapter 00E1677 2E28, 2E52
1 IBM Flex System 2-port 10 Gb RoCE adapter 90Y3481 2770
1 IBM Flex System 2-port 16 Gb Fibre Channel adapter 95Y2389 2750
1 IBM Flex System 4-port 16 Gb Fibre Channel adapter 95Y2394 2755
2
7895-22X management card:
v Management card (CCIN 52EA) for 3.3 GHz, 8-core
system board
v Management card (CCIN 52EC) for 3.2 GHz, 16-core
system board
v Management card (CCIN 52E8) for 3.5 GHz, 16-core
system board
v 00E0706
v 00E0705
v 00E0704
2
7895-23A management card:
v Management card (CCIN 52B3) for 4.0 GHz, 4-core
system board
00E2942
2
7895-23X management card:
v Management card (CCIN 52ED) for 4.0 GHz, 8-core
system board
v Management card (CCIN 52EF) for 3.6 GHz, 16-core
system board
v Management card (CCIN 522E) for 4.1 GHz, 16-core
system board
v 00E1742
v 00E1736
v 00E1733
2
1457-7F2 management card:
v Management card (CCIN 52EF) for 3.6 GHz, 16-core
system board
v Management card (CCIN 522E) for 4.1 GHz, 16-core
system board
v 00E1736
v 00E1733
3 Light path diagnostics panel 81Y5290
4 Bezel 00J0456
4 OEM bezel 00J0455
5 3.0V battery 33F8354
6
Memory, 2 GB DDR3, 1066 MHz low profile (LP)
DIMM
Note: 7895-22X only.
78P1011
6
Memory, 4 GB DDR3, 1066 MHz very low profile (VLP)
DIMM
78P0501
Chapter 7. Parts listing for IBM Flex System p260 and p460 Compute Nodes 99
