The following figure shows LEDs on the system board of the IBM Flex System p460 Compute Node.
The following table identifies the light path diagnostic LEDs.
Table 21. IBM Flex System p260 Compute Node and IBM Flex System p460 Compute Node LEDs
Callout Unit LEDs
▌1▐ 3 V lithium battery LED
▌2▐ DRV2 LED (HDD or SSD)
Figure 47. LED locations on the system board of the IBM Flex System p260 Compute Node
Figure 48. LED locations on the system board of the IBM Flex System p460 Compute Node
