IBM System x3250 Problem Determination And Service Guide

Replaceable server components
Replaceable components are of three types:
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for
the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
For
information about the terms of the warranty and getting service and assistance,
see the Warranty and Support Information document.
Table 4. Parts listing, Type 8872 and 8874
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
1 Cover 42C1284
2 Low-profile adapter varies
3 Riser card 42C1278
4 3/4-length adapter varies
5 SAS/SATA controller card (hot-swap models) (models 44x,
52x, 54x, 62x, 64x 4Dx, 5Bx, 5Dx 6Bx, 6Dx)
42C1279
6 System board assembly 42C1276
7 SAS/SATA backplane, 3.5-inch drives (hot-swap models)
(models 44x, 52x, 62x 4Dx, 5Bx, 6Bx)
39M4349
8 SATA simple-swap hard disk drive back plate, 3.5-inch
drives (models 12x, 22x, 42x, 1Bx, 2Bx, 4Bx)
39M4347
9 Power supply, 351 W 39Y7289
10 SAS/SATA backplane, 2.5-inch drives (hot-swap models)
(models 54x, 64x 5Dx, 6Dx)
39Y9541
11 Drive cage, 2.5-inch (models 54x, 64x, 5Dx, 6Dx) 42C1287
12 Hard disk drive, 2.5-inch, 36 GB, 10K, HS SAS (optional) 39R7364
12 Hard disk drive, 2.5-inch, 73 GB, 10K, HS SAS (optional) 39R7366
13 Hot-swap SAS filler panel, 2.5-inch (models 54x, 64x,
5Dx, 6Dx)
26K8680
14 Fan (40 mm) 39M4322
15 Drive cage, 3.5-inch (models 12x, 22x, 42x, 44x,52x, 62x
1Bx, 2Bx, 4Bx, 4Dx, 5Bx,6Bx)
42C1286
16 Bracket ear 39M4351
17 Hard disk drive, 3.5-inch, 73 GB, 10K, HS SAS (optional) 39R7340
17 Hard disk drive, 3.5-inch, 146 GB, 10K, HS SAS (optional) 39R7342
17 Hard disk drive, 3.5-inch, 300 GB, 10K, HS SAS (optional) 39R7344
17 Hard disk drive, 3.5-inch, 36 GB, 15K, HS SAS (optional) 39R7346
17 Hard disk drive, 3.5-inch, 73 GB, 15K, HS SAS (optional) 39R7348
17 Hard disk drive, 3.5-inch, 146 GB, 15K, HS SAS (optional) 39R7350
60 IBM System x3250 Types 4364 and 4365: Problem Determination and Service Guide

IBM System x3250 Specifications

General

Processor Sockets	1
Memory Slots	4
Processor	Intel Core 2 Duo
Storage	SATA
Maximum Internal Storage	Up to 4TB
Hard Drive Interface	SATA
RAID Support	RAID 0, 1
Network	Gigabit Ethernet
Operating System Support	Windows Server, Linux
