Table 18. Parts listing, Type 7914 (continued)
Index Description
CRU part
number (Tier 1)
CRU part
number (Tier 2)
Labels, chassis 94Y7604
Labels, system service and FRU/CRU (2.5-inch) 94Y7605
Half high LTO Gen 3 SAS tape drive 46X5663
Half high LTO Gen 4 SAS tape drive 46X5672
Half high LTO Gen 5 SAS tape drive 46X5683
RDX 160 GB cartridge 46C5393
RDX 320 GB cartridge 46C5394
RDX 500 GB cartridge 46C5395
Internal RDX USB 3.0 drive dock 46C2346
External RDX USB 3.0 drive dock 46C2347
External RDX power adapter 81Y8905
Screw, four M3x5 screws 42C3933
Supercap pack 47C8696
Structural parts
Structural parts are not covered by the IBM Statement of Limited Warranty. The
following structural parts are available for purchase from the retail store.
Table 19. Structural parts, Type 7914
Index Description Part number
1 Top cover 94Y7569
5 Filler, PCI 94Y7608
8 Filler, power supply bay 94Y7610
Filler, single 2.5-inch hot-swap hard disk drive bay 44T2248
Filler, DVD drive bay 49Y4868
Filler, 2x2.5-inch simple-swap hard disk drive bay 59Y3925
14 Filler, 3.5-inch hot-swap hard disk drive 69Y5364
14 Filler, 3.5-inch simple-swap hard disk drive 69Y5368
Filler, fan 94Y7572
10 Chassis assembly, 2.5-inch HDD (without front bezel) 00AM324
10 Chassis assembly, 3.5-inch HDD (without front bezel) 00AM325
19 EIA brackets 94Y7570
27 Air baffle 94Y7568
Remote RAID battery/power module tray 94Y7609
ServeRAID M5110 series battery kit 81Y4491
Bracket, 3.5-inch to 5.25-inch conversion kit 32P4743
Bracket, tape mount kit 41Y7711
CMA kit 49Y4817
CMA kit, Gen-III 94Y6626
Slide rail kit, Gen-III 94Y6625
192 IBM System x3550 M4 Type 7914: Installation and Service Guide
