Table 1. Server features and specifications (continued)
Video controller (integrated into
IMM2):
v Matrox G200eR2
Note: The maximum video
resolution is 1600 x 1200 at 75 Hz.
SVGA compatible video
controller
DDR3 528 MHz SDRAM video
memory controller
Avocent Digital Video
Compression
16 MB of video memory (not
expandable)
Hot-swap fans:
v One microprocessor: 4 dual-motor
hot-swap fans.
v Two microprocessors: 6 dual-motor
hot-swap fans.
Power supply:
v Up to two hot-swap power
supplies for redundancy support
550-watt ac
750-watt ac
750-watt dc
Note: Power supplies in the server
must be with the same power rating
or wattage.
Integrated functions:
v Integrated Management Module II
(IMM2), which consolidates
multiple management functions in
a single chip.
v Intel I350AM4 Quad Port Gigabit
Ethernet controller with Wake on
LAN support
v Eight Universal Serial Bus (USB)
ports for 3.5-inch models. Seven
Universal Serial Bus (USB) ports
for 2.5-inch models. One port is for
optional USB flash device with
embedded hypervisor software is
installed.
v Six network ports (four 1 Gb
Ethernet ports on the system board
and two additional ports when the
optional IBM Dual-Port 10 Gb
Network Adapter is installed)
v One System Management 1 Gb
Ethernet port on the rear connected
to a systems management network.
This system management
connector is dedicated to the IMM2
functions.
v One serial port
RAID controllers (depending on the
model):
v A ServeRAID H1110 SAS/SATA
adapter that provides RAID 0, 1,
and 10.
v A ServeRAID M1115 SAS/SATA
adapter that provides RAID 0, 1,
and 10 with optional FoD RAID
5/50 and SED (Self Encrypting
Drive) upgrade.
v A ServeRAID M5110 SAS/SATA
adapter that provides RAID 0, 1,
and 10. Optional upgrade:
RAID 5/50 (512 MB Cache) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 (512 MB Flash) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 (1 GB Flash) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 and SED (Zero
Cache)
v A ServeRAID M5120 SAS/SATA
adapter that provides RAID 0, 1,
and 10. Optional upgrade:
RAID 5/50 (512 MB Cache) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 (512 MB Flash) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 (1 GB Flash) with
optional FoD RAID 6/60 and
SED upgrade
RAID 5/50 and SED (Zero
Cache)
8 IBM System x3550 M4 Type 7914: Installation and Service Guide
