5. Remove the retention clip from the side of the DVD drive filler panel. Save

the DVD drive filler panel for future use.

Note: If you are installing an optical drive that contains a laser, observe the

following safety precautions.

Statement 3

CAUTION:

When laser products (such as CD-ROMs, DVD drives, fiber optic devices,

or transmitters) are installed, note the following:

v Do not remove the covers. Removing the covers of the laser product could

result in exposure to hazardous laser radiation. There are no serviceable

parts inside the device.

v Use of controls or adjustments or performance of procedures other than

those specified herein might result in hazardous radiation exposure.

Figure 29. DVD drive filler panel removal

44 IBM System x3550 M4 Type 7914: Installation and Service Guide
