IBM x3550 User Manual

v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v See Chapter 3, “Parts listing, Type 7978 and 1913 server,” on page 29 to determine which components are
CRUs and which components are FRUs.
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Beep code Description Action
3-3-2 Critical SMBUS (I
2
C bus) error occurred.
1. Disconnect server power, wait 30 seconds
and retry.
2. Reseat the following components:
a. (Trained service technician only)
Microprocessor
b. PCI-X/PCI Express riser (if present)
c. PCI-X/PCI Express adapter (if present)
d. DIMMs
e. Hard disk drives
f. Hard disk drive backplane
g. Hard disk drive power cable
h. Hard disk drive signal cable (only for
SAS drive)
3. Replace the following components, one at
a time, in the order shown, restarting the
server each time:
a. (Trained service technician only)
System board
b. (Trained service technician only)
Microprocessor
c. PCI-X/PCI Express riser (if present)
d. PCI-X/PCI Express adapter (if present)
e. DIMMs
f. Hard disk drives
g. Hard disk drive backplane
h. Hard disk drive power cable
i. Hard disk drive signal cable (only for
SAS drive)
104 IBM System x3550 Type 7978 and 1913: Problem Determination and Service Guide

IBM x3550 Specifications

General

Processor Type	Intel Xeon
Chipset	Intel 5000P
Number of Processors Supported	2
Network Interface	Dual Gigabit Ethernet
Hard Drive Interface	SAS/SATA
Maximum Internal Storage	2.4 TB
Storage	Up to six 2.5-inch SAS or SATA hot-swap hard disk drives
Drive Bays	6
RAID Support	RAID 0, 1
Power Supply	670W or 835W
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESX
Memory	PC2-5300 Fully Buffered DIMMs (DDR2-667) or PC2-4200 Fully Buffered DIMMs (DDR2-533)
