SPECIFICATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
■ General
• Frequency coverage :
Receive
30 kH
z–60.000000 MHz*
1
*
2
Transmit
1.80
0–1.999999 MHz*
2
, 3.500– 3.999999 MHz*
2
5.33050*
3
, 5.34650*
3
, 5.36650*
3
,
5.37150*
3
, 5.40350*
3
,
7.00
0–7.300 MHz*
2
, 10.100–10.150 MHz,
14.00
0–14.350 MHz, 18.068–18.168 MHz,
21.00
0–21.450 MHz, 24.890– 24.990 MHz,
28.00
0–29.700 MHz, 50.000–54.000 MHz*
2
,
*
1
Some frequency bands are not guaranteed.
*
2
Depending on version. *
3
USA version only.
• Mode : SSB, CW, RTTY, AM
• Number of memory CH : 201 (split memory: 199; scan edges: 2)
channels
• Antenna connector : SO-239
• Antenna impedance : 50
ø (unbalanced)
• Usable temperature : –10°C to +60°C (+14°F to +140°F)
range
• Frequency stability : Less than
± 0.5 ppm
• Power supply : 13.8 V DC±15% (negative ground)
requirement
• Current drain : Transmit (at 100 W) 22 A
(at 13.8 V DC) Receive squelched 1.3 A
max. audio 2.0 A
• Dimensions : 241(W)
× 84(H) × 281(D) mm,
(projections not included) 9
1
⁄2(W) × 3
5
⁄16(H) × 11
1
⁄16(D) in
• Weight (approx.) : 5.5 kg (12.1 lb)
• CI-V connector : 2-conductor 3.5 (d) mm (
1
⁄8˝)
• ACC connector : 13-pin
■ Transmitter
• Output power
SSB, CW, RTTY : 2–100 W
AM : 1–25 W* (*Carrier power)
• Modulation system
SSB : Digital PSN modulation
AM : Digital Low power modulation
• Spurious emissions
HF bands : Less than
–50 dB
50 MHz band : Less than
–63 dB
• Carrier suppression : More than 50 dB
• Unwanted sideband : More than 50 dB
• Microphone : 8-pin connector (600
ø)
connector
• KEY connector : 3-conductor 6.3 (d) mm (
1
⁄4˝)
■ Receiver
• Receive system : Triple-conversion
superheterodyne
• Intermediate frequencies
1st : 64.455 MHz
2nd : 455 kHz
3rd : 15.625 kHz
• Sensitivity (10dB S/N, preamp: ON, Filter shape: sharp)
SSB, CW : Less than 0.16
µV
(1.8−29.7 MHz)
Less than 0.13
µV
(50 MHz band)
AM : Less than 13
µV
(0.5−1.799 MHz)
Less than 2
µV
(1.8−29.7 MHz)
Less than 1
µV
(50 MHz band)
• Squelch sensitivity (SSB, threshold, preamp ON)
: Less than 5.6 µV
• Selectivity
SSB*
(BW=2.4 kHz) : More than 2.4 kHz/–6 dB
Less than 3.6 kHz/–60 dB
CW*
(BW=500 Hz) : More than 500 Hz/–6 dB
Less than 900 Hz/–60 dB
RTTY
(BW=350 Hz) : More than 360 Hz/–6 dB
Less than 650 Hz/–60 dB
AM
(BW=6 kHz) : More than 6.0 kHz/–6 dB
Less than 15.0 kHz/–60 dB
*IF filter shape is set to SHARP.
• Spurious and image rejection ratio
: More than 70 dB
(except
1
⁄2 IF through on 50 MHz band)
• Audio output power : More than 2.0 W at 10%
distortion with an 8 ø load
(at 13.8 V DC)
• RIT variable range : ±9.999 kHz
• PHONES connector :
3-conductor 6.3 (d) mm (
1
⁄4˝)/8 ø
• EXT SP connector : 2-conductor 3.5 (d) mm (
1
⁄8˝)/8 ø
