Icom IC-7610

3
BASIC OPERATION
3-1
When rst applying power
Before turning ON your transceiver for the rst time,
make sure all connections are correctly made.
TIP: When you turn OFF the transceiver, it saves the
current settings. Therefore, when you turn ON the
transceiver again, it starts with the same settings.
z To turn ON the transceiver, push
POWER
.
z To turn OFF the transceiver, hold down
POWER
for
2 seconds until “POWER OFF...” is displayed.
Turning power ON or OFF
Rotate
AF RF/SQL
(inner) to adjust the volume level.
Adjusting the volume level
Selecting the VFO and Memory modes
VFO mode
You can set a frequency by rotating
MAIN DIAL
.
L Using the VFO mode may be easier for the rst
initial operation.
Memory mode
You can recall a frequency that you have memorized
on the MEMORY list.
Selecting the VFO mode or Memory mode
1. Push
QUICK
.
• The QUICK MENU screen is displayed.
2. Touch “VFO/MEMORY.”
3. Touch [VFO] or [Memory] to select the mode.
VFO indicator
After all connections are made, set the dials to the
positions described below.
q
w
e
r
t
y
q MAIN
AF RF/SQL
(inner): Fully counterclockwise
w MAIN
AF RF/SQL
(outer): 12 o’clock
e SUB
AF RF/SQL
(inner): Fully counterclockwise
r SUB
AF RF/SQL
(outer): 12 o’clock
t
KEY
SPEED
PITCH
(inner): Fully counterclockwise
y
KEY
SPEED
PITCH
(outer): 12 o’clock
VFO mode screen
Memory channel number
Memory mode screen
4. Push
EXIT
to close the VFO/MEMORY screen.
