REMOTE
ALC
Connects to a PC for
remote control using CI-V
commands.
3.5 mm (⅛ in) (d)
Input ALC voltage to the jack when
operating with a non-Icom linear
amplier.
• ALC voltage: –4 ~ 0 V
This terminal is used to control an
external equipment such as a non-Icom
linear amplier.
The terminal goes low when the
transceiver transmits. (RCA Plug)
USB port (type A)
Connects a USB A type keyboard, RC-28 remote
encoder, USB ash drive, mouse or hub.
L Turn OFF the transceiver power when connecting or
disconnecting.
NOTE:
• DO NOT connect a multimedia adapter, memory card
reader, USB HDD, USB ash drive, or Bluetooth
®
keyboard or mouse, as these are not supported by Icom.
• DO NOT connect two or more of the same USB devices.
(Example: Two USB hubs or two USB mice)
L Connect a PC keyboard for the RTTY and PSK
operations.
EXT KEYPAD
By connecting an external keypad with a circuit as
shown below to [EXT KEYPAD], you can output
memory content in 8 channel memories. You can
output memory contents such as that from a CW
Memory keyer (M1 ~ M8), Voice memory (T1 ~ T8),
RTTY Memory (RT1 ~ RT8), PSK memory (PT1 ~
PT8) to be transmitted.
z Push a switch to send the memory information.
z Hold down the switch for 1 second to repeatedly
send the memory information.
L To use the external keypad, turn ON the following
items.
MENU
»
SET > Connectors > External Keypad
• VOICE: ON • KEYER: ON
• RTTY: ON • PSK: ON
1.5 kΩ
±5%
1.5 kΩ
±5%
2.2 kΩ
±5%
4.7 kΩ
±
5%
1.5 kΩ
±5%
1.5 kΩ
±5%
2.2 kΩ
±5%
4.7 kΩ
±
5%
S5
S6
S7
S8
S1
S2
S3
S4
Mute switch: Mutes both transmission and
reception when the switch is turned ON.
External Keypad
GND
I/O
METER
Connects to an external
meter.
Outputs the received signal
strength or squelch level.
3.5 mm (⅛ in) (d)
• Output voltage: 8 V (maximum)
• Output impedance: 10 kΩ
L You can select the output signal from received
signal strength and squelch levels.
MENU
»
SET > Connectors
+
_
_
+
Main band
meter
Sub band
meter
ALC
GND
SEND
SEND
GND
L The T/R switching relay type can be changed on the
following screen.
MENU
»
SET > Connectors > SEND Relay Type
By connecting a PC keyboard to [USB], you can
output memory contents such as that from a CW
Memory keyer (M1 ~ M8), Voice memory (T1 ~ T8),
RTTY Memory (RT1 ~ RT8), PSK memory (PT1 ~
PT8) to be transmitted.
L To use this function, set the following items to ON.
MENU
» SET > Connectors >
Keyboard [F1]-[F8] (VOICE)
MENU
» SET > Connectors >
Keyboard [F1]-[F8] (KEYER)
