Icom IC-7610

3
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
3-6
Setting the frequency (Continued)
Entering a Split Frequency Offset
1. On the F-INP screen, enter the Split Frequency
Offset.
LTo enter a minus shift direction, touch [•(−)].
L Enter an offset between −9.999 MHz and +9.999 MHz
(1 kHz steps).
Entering a Memory channel
1. Push
QUICK
, and touch “VFO/MEMORY.”
2. Touch [MEMORY] to select the Memory mode.
Entry examples
• 10 kHz: [1], [0], [SPLIT]
• −1.025 MHz: [•(−)], [1], [0], [2], [5], [−SPLIT]
2. To save the entry, touch [SPLIT] or [−SPLIT].
• Closes the F-INP screen, and the Split function is
automatically turned ON.
3. Touch the MHz digits.
4. Touch [F-INP].
Touch for -Split
[SPLIT] or [-SPLIT]
is displayed
Memory mode
5. Enter a Memory channel number between 1 and
99. (Example: Memory channel 5)
L If you want to set a Program Channel number (P1 or
P2), enter “100” for P1, and “101” for P2.
6. Touch [MEMO] to save the entered channel.
• Closes the F-INP screen.
Dial Lock function
The Dial Lock function prevents frequency changes
caused by accidently rotating
MAIN DIAL
.
LThis function electronically locks the dial.
Hold down
SPEECH
for 1 second to turn the Dial
Lock function ON or OFF.
• “ ” is displayed while the function is ON.
• During Split Frequency operation, the Split Lock function
may be turned ON. (p. 4-10)
MENU
» SET > Function > Lock Function
Hold down
Shifted by the offset amount.
The Split function is ON.
