8-7
MENU
» SET > Network
DHCP (Default: ON( . . . ))
Turns the DHCP function ON or OFF.
IP Address (Default: 192.168. 0. 10)
Sets the static IP address.
Subnet Mask (Default: 255.255.255. 0 (24 bit))
Sets the subnet mask to connect to your PC or LAN
(Local Area Network), through the Ethernet.
Default Gateway (Default: —)
lf you are operating the IC-7610 using the optional
RS-BA1, a default gateway setting is required.
MENU
» SET > Connectors > CI-V
CI-V Baud Rate (Default: Auto)
Selects the CI-V data transfer rate.
L When “Auto” is selected, the baud rate is
automatically set according to the data rate of the
connected device.
CI-V Address (Default: 98)
Sets the CI-V address.
L“98h” is the default address of the IC-7610.
CI-V Transceive (Default: ON)
Turns the Transceive function ON or OFF.
CI-V USB/LAN→REMOTE Transceive Address
(Default: 00)
Sets the address used to remotely control the
transceiver or receiver using the optional RS-BA1,
through the [USB] port.
The external equipment control signal is output from
the [REMOTE] port.
CI-V Output (for ANT) (Default: OFF)
Enables outputting the antenna controller status
(frequency and so on) from the [REMOTE] port.
L Address “01h” is reserved.
The usable addresses are limited to 02h ~ DFh.
CI-V USB Port (Default: Unlink from [REMOTE])
Selects the internal connection type between the
[USB] and [REMOTE] CI-V ports.
CI-V USB Baud Rate (Default: Auto)
Selects the CI-V data transfer rate when remotely
controlling the IC-7610 through the [USB] CI-V port .
L When “Auto” is selected, the baud rate is
automatically set according to the data rate of
external device.
L This setting is valid only when the “CI-V USB Port”
item is set to “Unlink from [REMOTE].”
CI-V USB Echo Back (Default: OFF)
Turns the Data Echo Back function ON or OFF, when
remotely controlling the IC-7610 through the [USB]
CI-V port.
L This setting is valid only when the “CI-V USB Port”
item is set to “Unlink from [REMOTE].”
MENU
» SET > Connectors > External Meter
External Meter Output (MAIN) (Default: Auto)
External Meter Output (SUB) (Default: Auto)
Selects the parameter (Main and Sub readout) to
output to an external meter.
External Meter Level (MAIN) (Default: 50%)
External Meter Level (SUB) (Default: 50%)
Sets the output level to the external meter (Main and
Sub band).
MENU
» SET > Connectors
Decode Baud Rate (Default: 9600)
Selects the data transfer rate (Baud rate) of decoded
signals.
SEND Relay Type (Default: MOS-FET)
Selects the switching relay type for [RELAY].
Select the suitable relay type, especially when
connecting a non-Icom linear amplier.
ACC BAND Voltage Output (Default: TX)
Selects the operating band voltage output from
[ACC2] (pin 4).
MIC Input DC Bias (Default: ON)
Outputs the 8 V bias voltage (approximate) from the
microphone connector (pin 1 of [MIC]).
REF IN (Default: OFF)
Selects the transceiver’s reference frequency signal
source.
LThis setting will be valid after restarting the transceiver.
L If the applied reference signal is off frequency, or not high
enough, the IC-7610 will not work correctly. In that case,
select “OFF,” and then restart the IC-7610.
Network
