SPECIFICATIONS
D General
• Frequency coverage:
IC-A14 TX 118.000 to 136.975 MHz
RX 108.000 to 136.975 MHz
WX (Rx only) 161.650 to 163.275 MHz
IC-A14S TX/RX 118.000 to 136.975 MHz
• Mode: 6K00A3E
16K0G3E (IC-A14/Rx only)
• Channel spacing: 25 kHz
• Number of memory channels:
IC-A14 200 (20 CH × 10 BANKS)
IC-A14S 100
• Power supply requirement: Specified Icom’s battery packs
7.4 V DC standard
• Usable temperature range: –10˚C to +60˚C (+14°F to +140°F)
• Current drain (at 7.4 V DC):
Tx 1.5 A
Rx at stand by 50 mA typical
at AF max. 500 mA
• Antenna connector: BNC 50 Ω (nominal)
• Dimensions: 53 (W) × 120 (H) × 36.9 (D) mm
(projections not included) 2.1 (W) × 4.7 (H) × 1.5 (D) inch
• Weight: Approximately 180 g (6.35 oz)
(Without the battery pack and antenna.)
D Transmitter
• Output power : 5.0 W (PEP) typical
1.5 W (CW)
• Modulation: Low level modulation
• Modulation limiting: 70 to 100%
• Frequency stability: ±5 ppm
• Audio harmonic distortion: Less than 10% (at 60% modulation)
• Hum and noise ratio: More than 35 dB
• Spurious emissions: More than 46 dB
(except operating
frequency ±62.5 kHz range)
• External MIC connector: 3-conductor 2.5(d) mm (
1
⁄10˝)/
150 Ω
D Receiver
• Receive system: Double conversion superhetero-
dyne
• Intermediate frequencies: 1st 46.35 MHz, 2nd 450 kHz
• Sensitivity:
COM band (6 dB S/N) –6 dBµ typical
NAVI band (6 dB S/N) –3 dBµ typical (IC-A14 only)
WX channels (12 dB SINAD) –13 dBµ typical (IC-A14 only)
• Squelch sensitivity (threshold): AM Less than 0 dBµ
FM Less than –5 dBµ
(IC-A14 only)
• Selectivity: 6 dB (More than 7.5 kHz)
60 dB (Less than 25 kHz)
• Spurious response rejection: AM More than 60 dB
FM More than 30 dB
(IC-A14 only)
• Audio output power: More than 700 mW (internal SP)
( at 10% distortion into an 8 Ω More than 500 mW (external SP)
load, 30% modulation)
• Hum and noise: More than 35 dB at 30% mod.
• External SP connector: 3-conductor 3.5 (d) mm (
1
⁄8˝)/8 Ω
All stated specifications are subject to change without notice or obligation.
