PANEL DESCRIPTION
■ Function display
q FUNCTION ICON
Appears when [FUNC] is pushed.
w MEMORY ICON (p. 12)
Appears when memory channel mode is selected.
e TAG ICON (p. 20)
Appears when the selected memory channel is set as a
TAG channel.
r RX ICON (p. 10)
Appears while receiving a signal, or when the squelch is
open.
t TX ICON (p. 10)
Appears while transmitting.
y DUPLEX ICON (IC-A14 only) (p. 24)
➥ Appears when the duplex function is activated.
➥ Blinks while setting the duplex frequency.
u ANL ICON (p. 22)
Appears when the ANL (Automatic Noise Limiter) func-
tion is in use.
i WEATHER ALERT ICON (IC-A14 only) (p. 23)
Appears when the weather alert function is in use.
o LOCK ICON (p. 9)
Appears when the lock function is in use.
!0 LOW BATTERY ICON (p. 11)
➥ Appears when the battery is nearing exhaustion. The
attached battery pack requires recharging when this
icon appears.
➥ Blinks when battery recharging/replacing is immedi-
ately needed.
!1 FREQUENCY READOUT
Displays the operating frequency, memory channel num-
ber, memory name or the Set mode item, and so on, de-
pending on the selected mode.
qwer tyuio
!0
