7
BATTERY PACKS AND CASE
D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
simultaneously charged. The following are additionally re-
quired.
• Six AD-106 charger adapters.
• A power adapter (BC-157S) or the DC power cable (OPC-656).
■ Battery case
(optional for some versions)
D Precaution
NEVER incinerate used battery cells since internal battery
gas may cause them to rupture.
NEVER expose a detached battery case to water. If the bat-
tery case gets wet, be sure to wipe it dry before using it.
NEVER short the terminals of the battery case. Also, cur-
rent may flow into nearby metal objects. Therefore, be care-
ful when carrying with, or placing near metal objects, carrying
in bags and so on.
When installing battery cells, make sure they are all the same
brand, type and capacity. Also, do not mix new and old bat-
tery cells together.
Install conventional alkaline cells only. Other type of batter-
ies, such as Ni-Cd, Ni-MH, Li-ion, cannot be used.
Remove the alkaline cells when leaving the battery case un-
used for long time.
Keep battery contacts clean. It’s a good idea to occasionally
clean the battery terminals.
Alkaline cells have a shorter operating time compared to
Li-ion battery cells. Also, the operating time differs by brand,
as well as the model type of the alkaline cell being used.
Therefore, it is recommended that you use the Li-ion battery
pack, or take spare alkaline cells with you when intending to
use the transceiver frequently, or for long periods.
Battery
pack
AD-106 charger
adapters are installed
in each slot.
wer adapter
(User supplied)
Transceiver
Tu rn power OFF
DC power cable
(OPC-656)
(Connect with the
DC power supply,
IMPORTANT!:
Ensure the guide tabs
on the battery pack are
correctly aligned with
the guide rails inside
the charger adapter.
Guide rails
Tabs
31
