Icom IC-R6 User Manual

43
8
TONE SQUELCH AND POCKET BEEP
New2001
■ Tone/DTCS squelch operation
q Set a desired frequency in the FM mode.
w Hold down [SET](TS) for 1 second to enter the Set mode.
e Rotate [DIAL] to select the “EXPAND” item.
r While holding down [FUNC], rotate [DIAL] to turn the
Expand set mode ON.
t Rotate [DIAL] to select the “TSQL” item.
y While holding down [FUNC], rotate [DIAL] to select a
desired subaudible tone setting from “TSQLS,” “TSQL,”
“DTCSS,” “DTCS,” “T SQL-R,” “DTCS-R” or “OFF.”
Tone squelch
DTCS squelch
Tone squelch (reverse)
DTCS squelch (reverse)
Tone squelch with pocket beep
DTCS squelch with pocket beep
u Push [SET](TS) to exit the Set mode.
• Either “S T SQL,” T SQL,” “SDTCS,” “DTCS,” “T SQL-R” or
“DTCS -R” appears, according to the tone selection in step y.
Tone squelch
DTCS squelch
DTCS squelch (reverse)
Tone squelch (reverse)
Tone squelch with pocket beep
DTCS squelch with pocket beep
i When a signal with the matched tone is received, the
squelch opens and audio is heard.
When the pocket beep function is activated, the receiver
also emits beep tones and blinks “S.”
• Beep tones sound and “S” blinks for 30 seconds.
o Push [FUNC] to manually stop the beeps and blinking.
• “S” disappears and the pocket beep function is deactivated.
!0 To cancel the tone squelch or DTCS, set the “TSQL” item
to “OFF” in the Expand set mode, as described in step y.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
