Icom IC-R6 User Manual

79
New2001New2001
OPTIONS
15
• BC-196SA/SD ac adapter
• BC-153SC ac adapter
For regular charging of the installed Ni-MH batteries. Same
as supplied one. (Not supplied with some receiver version.)
BC-196SA/SD : 4.5 V DC/400 mA output
BC-153SC : 6.0 V DC/1 A output
• CP-18A/E cigarette lighter cable with dc-dc converter
Allows you to operate the receiver through a 12 V cigarette
lighter socket. You can also charge the installed Ni-MH bat-
teries.
• BC-194 charger stand
Allows you to charge the receiver on the desktop. Requires
an AC adapter or cigarette lighter cable.
• AD-92SMA antenna connector adapter
Allows you to connect an external antenna with a BNC
connector.
• SP-13 earphone
Provides clear audio in noisy environments.
• HP-4 headphone
Light weight monaural headphone.
• LC-146A carrying case
Helps protect the receiver from scratches, etc.
• CT-17 ci-v level converter
For receiver remote control using a PC.
• OPC-474 cloning cable
For receiver-to-receiver cloning.
• OPC-478/OPC-478UC cloning cable
Used for data cloning between receiver and a PC with
CS-R6 (cloning software).
• CS-R6 cloning software
Provides quick and easy programming of such settings as
memory channels and Set modes contents via your PC’s
RS-232C terminal (using OPC-478), or USB port (OPC-
478UC). Either OPC-478 or OPC-478UC is required.
Approved Icom optional equipment is designed for optimal
performance when used with an Icom receiver.
Icom is not responsible for the destruction or damage to an
Icom receiver in the event the Icom receiver is used with
equipment that is not manufactured or approved by Icom.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
