Icom IC-R6 User Manual

44
8
TONE SQUELCH AND POCKET BEEP
New2001
8
■ Tone scan
By monitoring a signal that is being operated with pocket
beep, tone or DTCS squelch function, you can determine the
tone frequency or DTCS code necessary to open a squelch.
q Set the frequency to be checked for a tone frequency or
code.
w Turn a desired tone type, tone squelch or DTCS ON in the
Expand set mode.
• One of “TSQL” or “DTCS” appears.
• Even the pocket beep function is activated, the function is can-
celled when starts the tone scan.
e While holding down [FUNC], push [ ](MODE) to start
the tone scan.
• To change the scanning direction, rotate [DIAL].
[DIAL]
Tone squelch scan
DTCS squelch scan
r When the CTCSS tone frequency or 3-digit DTCS code
is matched, the squelch opens and the tone frequency or
code is temporarily programmed into the selected condi-
tion, such as memory channel.
• The tone scan pauses when a CTCSS tone frequency or 3-digit
DTCS code is detected.
NOTE: The decoded tone frequency or code is pro-
grammed temporarily when a memory channel is selected.
However, this will be cleared when the other memory chan-
nel is selected.
✔ For your convenient!
Even no tone type is selected, either tone squelch or DTCS,
pushing [ ](MODE) while holding down [FUNC] also
start tone scan. In this case, the tone scan searching for
tone squelch frequency only.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
