Icom IC-R6 User Manual

62
10
OTHER FUNCTIONS
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
e Push [SQL] on the master receiver.
• The receiver displays the following.
During cloning
After cloning
Master receiver display Sub-receiver display
r When cloning is finished, turn power OFF, then ON to exit
the cloning mode.
D Cloning using a personal computer
Data can be cloned to and from a personal computer
(Microsoft
®
Windows
®
2000/XP/Windows Vista
®
or Windows
®
7)
using the optional CS-R6 cloning software and the option-
al OPC-478/OPC-478UC cloning cable. Consult the CS-R6
cloning software HELP file for details.
D Cloning error
NOTE: DO NOT push any key on the receiver during
cloning. This will cause a cloning error.
When the display appears as shown below, a cloning error
has occurred.
In such a case, receiver automatically returns to the clone
standby condition and cloning must be repeated.
Microsoft, Windows and Windows Vista are registered trademarks of Microsoft
Corporation in the U.S.A. and other countries.

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
