Icom ID-4100A

BASIC MANUAL
xiii
New2001 New2001
TABLE OF CONTENTS
IMPORTANT ......................................................................... i
EXPLICIT DEFINITIONS ....................................................... i
SUPPLIED ACCESSORIES .................................................. i
ABOUT THE CONSTRUCTION OF THE MANUAL ............. ii
OPTIONS .............................................................................iii
TABLE OF CONTENTS BY TOPIC ..................................... iv
PRECAUTIONS .................................................................... v
IMPORTANT NOTES ..........................................................vii
DÉFINITIONS EXPLICITES ................................................ ix
PRÉCAUTIONS .................................................................... x
INFORMATION FCC ...........................................................xii
MISE AU REBUT .................................................................xii
1 INSTALLATION AND CONNECTIONS ............ 1–8
■ Attaching the controller ...............................................1
■ Installing the controller ................................................ 2
■ Connecting a microphone ........................................... 3
■ Connecting to a DC power supply ..............................3
■ Installing in a vehicle ...................................................4
■ Installing an antenna ...................................................5
■ Connecting to a battery ...............................................6
■ Installing the UT-137 ...................................................7
■ Electromagnetic Interference ...................................... 8
2 PANEL DESCRIPTION ................................... 9–18
■ Controller — Front panel ............................................9
■ Controller — Display ................................................. 11
■ Main unit — Front panel ...........................................14
■ Main unit — Rear panel ............................................15
■ Microphone (HM-207S) ............................................16
3 BASIC OPERATION ..................................... 19–26
■ Turning ON the transceiver .......................................19
■ Monitor function ........................................................19
■ Setting audio volume and squelch level ...................19
■ Quick Menu window ..................................................20
■ Selecting the Mode ...................................................21
■ Selecting the operating band ....................................22
■ Selecting the operating mode ...................................22
■ Setting a frequency ................................................... 23
■ Lock function .............................................................24
■ DR function ...............................................................24
■ Speech function ........................................................25
■ Home Channel function ............................................25
■ Transmitting ..............................................................26
4 MENU SCREEN ............................................ 27–40
■ MENU screen description .........................................27
■ Selecting a Menu item ..............................................27
■ Menu items and their details ..................................... 28
