Icom IP730D - Advanced Operation; D about the Talkgroup Call

3
USING THE CELLULAR MODE
3-4
Advanced operation
D About the Talkgroup Call
The Talkgroup Call function enables the user to communicate with call-to parties in the same Talkgroup�
For example, in the illustration below, when the IP730D “00105” in its normal group “10002” selects Talkgroup
“20001,” it is excluded from group “10002,” and can communicate with only the transceivers “00004” and “00108”
that belong to Talkgroup “20001�”
L This function can be used for only when the Talkgroup number is registered, and the Talkgroup Call function is assigned to a
key by your dealer�
L Ask your dealer about whether or not to include the Talkgroup in the All Call�
Group 10001 Group10002
00001 00002 00003
00004 00105 00106 00107
00108
Talkgroup 20001 Talkgroup 20002
All
When Talkgroup is selected
Group 10001 Group 10002
00001 00002 00003 00106 00107
Talkgroup 20001
00004
00108
00105
Talkgroup 20002
When Talkgroup is OFF
All
