• Channel output breakers must not exceed 30 amps max
rating for 12- and 24-volt DC systems, 20 amps max rating
for 48-volt DC systems.
• Install unit in a restricted access location (such as an
equipment rack) to limit unintentional contact with terminals
and wiring.
• Keep sources of moisture away from unit.
• Ensure all breakers are in the "OFF" position before
connecting or disconnecting wiring.
• Do not energize the unit before the chassis ground is
connected.
• Ensure the total power consumption of the loads does not
exceed the 100 amps (peak) rated capacity of each power
bus.
The following is the recommended sequence for the installation process.
2.1 Quick Install Guide
• Unpack and check that the unit and all materials have been
delivered.
• Obtain the recommended tools.
• Mount the unit.
• Connect the ground according to the site design, and in
accordance with local electrical code standards.
• Connect the sensors and alarms.
• Connect the loads.
• Insert the breakers.
• Verify system wiring.
• Connect and energize the DC inputs.
• Configure the software settings.
• Energize the loads.
2.2 Unpacking and Inspection
Perform a physical check of the unit as it is being taken out of the box to
ensure it has not been damaged during shipping. Check that the
accessories under the package contents section were shipped with the unit.
NOTE: In case of shipping damage, your freight carrier should be notified
immediately.
