3.2.2 Network Screen
The Network screen will show the network status, connection type, IP
address assigned to the unit, and the MAC address of the unit.
Other information will be shown depending on the operating state of the unit:
• The network status will display either "Network Connected" or "No
Network".
• The connection type will display either "100 Base-Tx" or "10 Base-
Tx".
3.2.3 Output Screen (1A to 6A or 1B to 6B)
The Output screen will show the channel number and name of the load
(inputted by the user), channel output status, output voltage, and channel
output current. Each output channel may be given a unique name to
describe the actual load connected using the Output Setup section of the
GUI (see Section 4.6).
Other information will be shown depending on the operating state of the unit:
• The channel output status will display "ENABLED", "DISABLED" to
indicate internal relay state or "BREAKER OFF" if the overcurrent
device for the channel is tripped.
• The output voltage will blink if it exceeds the overvoltage or
undervoltage alarm thresholds.
• The channel output current will blink if it exceeds the overcurrent
or undercurrent alarm threshold for that channel.
Press either "Output Select" button to scroll through the
output screens before moving to the Site Alarm Input
Screen.
