ICT Distribution 3 Series User Manual

Distribution Series 3 Dual Bus
855-314-002_Rev2.0_Instruction Manual
Page 44 of 46
6.11 How do I log out of the GUI?
To log out of the ICT Distribution Series 3 GUI, click on the Logout link on
the top right of the browser window. The system will also automatically log
off the user after 20 minutes of inactivity.
7.0 PRODUCT SPECIFICATIONS
7.1 Electrical Specifications
Table 6. Electrical Specifications
Parameters
Rating
Operating Voltage (POS or
NEG ground)
10 to 60 VDC
Current Rating per Bus
100 A max, 80 A continuous
Outputs per Bus
6 (normally closed)
Max Output Rating (12/24 V)
30 A peak (25 A continuous)
4
Max Output Rating (48 V)
20 A peak (16 A continuous)
4
Meter Accuracy, Voltage
Bus voltage readings +/−1%
Meter Accuracy, Current
Channel current readings +/− 3%
Power Consumption
< 21 W (all outputs disabled)
< 5 W (all outputs enabled)
Network Communications
RJ45 10/100-T port (IPv4, HTTP, HTTPS, SMTP, DNS,
TCP, UDP, ICMP, DHCP, ARP, SNMP v1/v2c/v3)
Network Security
Password protection, SSL encryption for HTTPS and
SMTP (TLS 1.2)
7.2 Physical Specifications
Table 7. Physical Specifications
Parameters
Configuration
Outputs
Floating
Alarm Output
2x Form-C contact, 1 A 60 VDC max
Input Connector
4x Insulated M8 stud, with slip-on insulating boot, 75 in-lb.
(8.47 N-m) max torque
Output Connector
2x 12 position cage clamp type
10–22 AWG, 5.22 in-lb. (0.59 N-m)
Alarm Output Connector
2x 3-pin removable plug cage clamp type 16–28 AWG
Alarm Input Connector
10-pin removable plug, cage clamp type 16–28 AWG
Operating Temperature
−20°C to +60°C (Derate max bus current by 2% per
degree C above 50°C)
Storage Temperature Range
−45 to +85°C
Humidity
(Operating) 10–90% (non-condensing)
(Storage) 5–95% (non-condensing)
Cooling
Convection (no fan)
4
In accordance with NEC Section 210.20(A)
