Model 252
Label Printer/Applicator
Operators/Technical Manual
13
Figure 9: External Connectors
External Connector (2X)
9 pin Female D Connector
PIN
FUNCTION
1
Product Detect Signal 2
Sinking (NPN) Input
2
Red Beacon Lamp
Sinking (NPN) Output
3
Product Detect Signal 1
Sinking (NPN) Input
4
Accessory Signal
Sinking (NPN) Input
5
0 V
6
+24 VDC
7
Amber Beacon Lamp
Sinking (NPN) Output
8
Green Beacon Lamp
Sinking (NPN) Output
9
Reserved
The external connectors and signals are designed to work with ID Technology standard
accessories. Use of non-approved components may give unexpected results, may lead to
equipment damage and may void warranty.
