Model 252
Label Printer/Applicator
Operators/Technical Manual
46
5.4.4 Airjet Mode
This selection enables the configuration of the applicator to apply a label using a vacuum
tamp pad mounted on an air cylinder. The pneumatics used in the airjet mode are
enabled and all other configurations are disabled.
The Airjet Mode Cycle:
1) The label is printed and dispensed onto the tamp pad.
2) The vacuum valve is enabled, creating a vacuum through the holes in the
tamp pad, which holds the label in place.
3) When a product detector signal is received, the tampjet valve opens releasing
a blast of air which is routed through the holes in the vacuum tamp pad
overcoming the vacuum.
4) The label is aerodynamically propelled toward the product.
5) Adhesive on the label attaches the label to the product.
Specialty firmware versions may not support this mode of operation.
These versions will not display this option.
