1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET
2
OF
2
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
02
.000
ANGLE
1
005
STANDARD
TOLERANCE
clari
10/10/2012
ID100033 / ID100034
ASSY,FRAME 252 BASE MODULE
C
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1 1
15134a ELECTRICAL HAZARD LABEL
2
1
6010 LABEL,ELECTRICAL HAZARD
3 2 60224
WASHER,DIRECTIONAL .8 OD X .25 ID
4 1
62011 BASE PLATE BRACKET
5
1
62015-08
COLLAR, GUIDE 1"
6
1
62030-16 ROLL,IDLER
7
2 62031 SHAFT,IDLER
8 2 62034 ROLL,SPACER
9
1
62120 FILTER REGULATOR ASSEMBLY
10
1
62180
TUBE,AIR ASSIST
11 1
ID100001 ASSY,252 ELECTRONIC MODULE
12
1
ID100004 BASEPLATE,252
13
1
ID100005 BRACKET,UNIVERSAL
14 1
ID100006 BLOCK,TRUNION - SET ROTATION
15 1
ID100007
ID100008
COVER,BACK 252 RH
COVER,BACK 252 LH
16
1
ID100009
ID100010
NAMEPLATE,252 RH
NAMEPLATE,252 LH
17 1
ID100011 BRACKET,AIR ASSIST
18
1
ID100035 ASSY,IDLER ROLLER
19
1
ID100037
ID100038
ASSY,PNEUMATICS 252 RH
ASSY,PNEUMATICS 252 LH
20
1
ID100048
ID100049
Label,Threading Diagram 252 RH
Label,Threading Diagram 252 LH
21 2 M20x50 HHCS
22
1
M4x10 SHCS
23
4
M4x20 SHCS
24 2 M4x25 SHCS
25 2 M4x8 SHCS
26 2 M5x12 SHCS
27
5
M5x14 SHCS
28 2 M5x20 SHCS
29 2 M6x10 PPHS
30
4
M6x20 SHCS
31 2 M6x35 SHCS
32
4
M6x55 SHCS
33 2 M6x60 SHCS
34
1
M8x45 SHCS
35 2
Washer,Flat M20 Zc Plt
36
4
Washer,Flat M4 SS
37 2
Washer,Flat M5 SS
38 8
Washer,Flat M6 SS
39
1
Washer,Flat M8 SS
40 2
Washer,Lock Split M20 SS
41
2
Washer,Lock Split M4 SS
42 2
Washer,Lock Split M5 SS
43 8
Washer,Lock Split M6 SS
44
1
Washer,Lock Split M8 SS
