ID Technology 252 - Page 137

Model 252
Label Printer/Applicator
Operators/Technical Manual
21
1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET 2 OF 2
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
02
.000
ANGLE
1

005
STANDARD
TOLERANCE
clari
10/9/2012
ID100013 / ID100014
ASSY,UNWIND 14"
C
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1 1
60224 WASHER,DIRECTIONAL .8 OD X .25 ID
2
1
62005
HUB,UNWIND
3
1
62007
LABEL,UNWIND HUB
4 1
62022 SHAFT,UNWIND
5
1
62024
BAND,BRAKE
6
1
62027 PIN, SPRING ANCHOR
7 1
62028 SPRING,EXTENSION
8 2 62029 BEARING
9
1
62030-08 ROLL,IDLER
10
1
62031
SHAFT,IDLER
11
2 62032
BUSHING,FLANGED 1/2" BRONZE
12
1
62036 HUB,UNWIND OUTER LOCKING
13
1
62037 INSERT,HUB LOCKING
14 1
ID100015 BLOCK,UNWIND
15 1
ID100016
ARM,DANCER 14.5" UNWIND
16
1
ID100017 SHAFT,DANCER
17 1
ID100018 COLLAR, SPRINGBREAK
18
1
ID100019 SPUR HUB
19
1
ID100020 SPUR,LOCKING
20
1
ID100036
DISC,UNWIND 14.5"
21
1
ID100047
KEEPER,MEDIA SUPPLY 14.5"
22
1
DRIVE PIN (SPRING)
23
2
DRIVE PIN (BRAKE BAND ANCHOR)
24 2
Internal Retaining Ring, 1.653"
25 6 M4x12 SBHCS
26
1
M6x10 PPHS
27
1
M6x12 SHCS
28
1
M6x20 SFHCS
29
1
M6x20 SHCS
30 2 M8x8 SSS Cup SS
31
1
External Retaining Ring, 1"
32 2
External Retaining Ring, 1/2"
33
1
External Retaining Ring, .781"
