ID Technology 252 - Page 146

Model 252
Label Printer/Applicator
Operators/Technical Manual
30
Figure 21: Exploded View, ID100240-12-XX Dual Panel Tamp Assembly NU/ND
1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET 1 OF 2
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
 02
.000
ANGLE
 1 

005
STANDARD
TOLERANCE
clari
8/5/2013
ID100240-12-XX
MODULE,DUAL TAMP,252 12"Stk XX"Swg
Nu/d
C
THE INFORMATION
CONTAINED IN THIS
DRAWING IS THE SOLE
PROPERTY OF I D
TECHNOLOGY.
REPRODUCTION IN PART OR
WHOLE WITHOUT THE
WRITTEN PERMISSION OF ID
TECHNOLOGY IS
PROHIBITED.
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1
2
External Retaining Ring,
1/2"
2
14
M4x25 SHCS
4
8 M5x20 SFHCS
5
2 M5x20 SHCS
6
7
M6x12 SHCS
7
2 M6x20 SHCS
8 8 M6x25 SHCS
9
7
M6x30 SHCS
10
7
M8x30 SHCS
11 4
M8x40 SHCS
12 6
Washer,Flat M6 SS
13
4
Washer,Flat M8 SS
14 7
Washer,Lock Split M6 SS
15 4
Washer,Lock Split M8 SS
16 2 00111 Z 20000 FITTING, BRASS BARB
17
2 00730 B 40818 BEARING,FLANGED
18
1
250-0266 BUTTON,NYLON
19 2 62203 BRACKET,CYLINDER
MOUNTING
20
1
62208 SHAFT,TAMP PIVOT
21
1
62209 ROD,SPACER
22
1
62237 BLOCK, ATTACHMENT
23
1
62262
BRACKET,TAMP
24
1
62360
KIT,SMART TAMP LASER
25
1
62651 PLATE, MOUNTING
26
1
62653-XX
PADDLE,TAMP
27 2 62654-XX PLATE SIDE
28
1
62655 CLEVIS
29
AR
62656 BRACKET,DAMPENING
30
1
62657 BRACKET,CYLINDER
MOUNTING (BACK)
31
1
6391K131 BEARING,SLEEVE OILITE
1/4x3/8x1/4
32
1
9546K242
BUMPER,MALE
33
1
MC-150 ASSY,SHOCK ABSORBER
34
1
NCM-PE075 BRACKET,PIVOT
35
1
NCME106-0600
6" PNUEMATIC CYLINDER
36
1
NY-106 CLEVIS,ROD
8
8
12
6
14
7
26
1
5
2
27
2
4
8
2
14
24
1
6
7
30
1
28
1
1
2
20
1
21
1
36
1
17
2
16
2
35
1
29
AR
33
1
18
1
32
1
22
1
34
1
19
2
31
1
*
*
* REPLACE THE -XX WITH THE
APPROPRIATE LENGTH PART
-08, -12, -16
