1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET
3
OF
3
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
02
.000
ANGLE
1
005
STANDARD
TOLERANCE
clari
1/17/2011
62870-XX RH
CORNER WRAP ASSY.-RH
C
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1 1 19155K96
COVER, FAN
2
1
1939K26
FAN (24VDC) (100 CFM)
3
1
3/8 - 16
Hex Nut
4 1
6 - 32x3/8 Phil Pan Head Machine
Screw
5 1
6072K32 BALL JOINT,HD
6 3 62027 PIN, SPRING ANCHOR
7 1
62028 SPRING,EXTENSION
8 2 62259 FLOW CONTROL,TAMPER
PROOF ELB 1/4Tx1/8UNI
9
1
62871-XX GRID
10
2 62872-XX
PLATE,SIDE
11 1
62873-XX PLATE,TOP
12 2 62874
PLATE,END
13
1
62875 BLOCK,MOUNT
14 1
62876 SHAFT,MAIN
15 1
62877 ROLLER
16
1
62878 SHAFT,ROLLER
17 1
62879 SPACER
18
1
62880 PIVOT,CYLINDER
19
1
62881 ARM,ROCKER
20
1
62882 PLATE,ADJUSTMENT
21
1
62883 GRID,STOP BLOCK
22
1
62884 GRID,STOP PIN
23
1
62885 BLOCK,BUMPER
24 1
62886-XX
BOX SHOE
25
1
62887-XX ARM,ROLLER
26 2 6338K472 BUSHING,FLANGE
3/4x7/8x5/8x1-1/8x1/8
27 2 90500-88 BEARING,SHAFT
28
1
9541K8
BUMPER,RUBBER
29
1
9546k66 BUMPER,MALE (RED)
30 3
1/2" X 0.010 SHIM
31
1
3/4 X 0.025
32
1
98380a546
PIN,DOWEL 1/4" X 1.5" S/S
33
1
External Retaining Ring,
5/8"
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
34
1
External Retaining Ring,
3/4"
35 2 AN103-X235
SILENCER,1/4" DIA.
36
1
C0720-055-0620S COMPRESSION SPRING
37
1
E0300-31-1000 SPRING,EXTENSION
38
1
DRIVE PIN (SPRING)
39
1
M3x5
Hexagon Socket Set Screw
- Cone Point
40 22
M4
Plain washer
41
16
M4
Spring Washer
42 2 M4x16
Socket Head Cap Screw
43 2 M4x20
Phil Flat Head Machine
Screw
44
10 M4x35
Socket Head Cap Screw
45 4 M4x45
Socket Head Cap Screw
46
1 M5
Plain washers
47 1 M5
Spring Washer
48
1
M5x12
Socket Head Cap Screw
49
4
M6
Plain washers
50 6 M6
Spring Washer
51 1
M6 Fender Washer
WASHER, FENDER M6
52
1
M6x12
Socket Head Cap Screw
53
1
M6x20
Hex Socket Flat Head Cap
Screw
54
2 M6x25
Socket Head Cap Screw
55
2 M6x35
Socket Head Cap Screw
56
1
M6x40
Socket Head Cap Screw
57
6 M8
Plain washer
58 6 M8
Spring Washer
59
7
M8x30
Socket Head Cap Screw
60
1
M8x45
Socket Head Cap Screw
61
1
NCME106-0200C
AIR CYLINDER, 2" STROKE
1-1/16" DIA.
62
1
External Retaining Ring,
1/2"
*
*
*
*
*
* REPLACE THE -XX WITH THE
APPROPRIATE LENGTH NUMBER.
i.e. -08, -10, -12
