28
7.7 Installation of the unit with coaxial probe
► Seal the process connection:
- For coaxial pipes with G¾ process connection:
Slide the supplied seal onto the thread of the coaxial pipe�
- For coaxial pipes with ¾" NPT process connection: Apply a suitable sealing
material (e�g� PTFE tape) to the thread of the coaxial pipe�
► Insert the unit with the coaxial pipe into the tank�
► Tighten it using a spanner� Tightening torque: 35 Nm
7.8 Alignment of the sensor housing
The sensor housing cannot be rotated with respect to the internal thread!
Subsequent alignment of the sensor housing is therefore not possible�
Therefore, the subsequent orientation of the housing (display orientation,
cable outlet) must be observed during installation of the process connection
on the tank lid�
