6
3 Items supplied
• 1 LR2050 level sensor
• 1 operating instructions
In addition, the following is necessary for installation and operation (→
Accessories):
• 1 rod (→ 12.1)
• as an option: 1 coaxial pipe (→ 12.2)
• mounting material (if necessary, a launching plate) (→ 12.1)
► In the event of incomplete or damaged items supplied please contact ifm
electronic�
► Only use accessories from ifm electronic�
Accessories: www�ifm�com
The optimum function is not ensured when using components from other
manufacturers�
4 Getting started
For the most frequent applications the quick set-up described below is possible�
The quick set-up does not replace observance of the other chapters�
► Install the unit correctly:
Installation distances (→ 7.1), Electrical connection (→ 8)�
► Setting the type of probe, probe length and medium (→ 11.2)�
> The unit is ready for operation.
Without changes = factory settings active (→ 15)�
Change of the factory settings (→ 11)�
► As an option, carry out a tank adjustment (→ 11.2.4)�
► If necessary, make more settings for adaptation to the application
(→ 11.3) and (→ 11.4)�
► Check whether the unit operates correctly�
