45
12.4 Operation indication
---- continuous Initialisation phase after power on
On delivery the unit is not operational� Basic settings required
(→ 11.2)�
[----] Level below the active zone
Numerical value +
LED 1
Current level in mm
Numerical value +
LED 2
Current level in inches
Numerical value +
LED 3
Current level in % of the scaled measuring range
LED 7 Switching status OUT2
LED 8 Switching status OUT1
[FULL] + numerical
value alternately
Level has reached or exceeded the maximum measuring range
(= overflow warning)�
[Sim] + XXX alternately Simulation active� XXX = state to be simulated (→ 11.7)
[S�On] Simulation stopped(→ 11.7)
[Loc] Unit locked via operating keys; parameter setting impossible�
For unlocking press the two setting buttons for 10 s�
[uLoc] Unit is unlocked / parameter setting is possible again
[C�Loc] The unit is temporarily locked� Parameter setting via IO-Link
active
[S�Loc] Unit is permanently locked via software� This locking can only
be removed via IO-Link�
12.5 Read the set parameters
► Briefly press [Enter] to open the menu�
► [▲] or [▼] scrolls through the parameters.
► Briefly press [Enter] to indicate the corresponding parameter value for about 30
s� Then the unit returns to the operating mode�
