10.2 Explanation of the menu
10.2.1 Main menu [I]
tREF Carry out tank adjustment�
Menu item only visible if [LEnG] ≥ 260 mm and [Prob] = [rod]
SP1 / rP1 Set point 1 / reset point at which OUT1 switches�
Menu item only visible if hysteresis function is selected ([ou1] = [H��])
FH1 / FL1 Upper / lower limit for the acceptable range within which OUT1 switches�
Menu item only visible if window function is selected ([ou1] = [F��])
ASP2 Analogue start point 2: Measured value at which the analogue start value is
provided� The analogue start value is set with parameter [ou2]� Menu item
only visible if analogue output is selected ([ou2] = [I] or [InEG])
AEP2 Analogue end point 2: Measured value at which the analogue end value is
provided� The analogue end value is set with parameter [ou2]� Menu item
only visible if analogue output is selected ([ou2] = [I] or [InEG])
SP2 / rP2 Set point 2 / reset point 2 at which OUT2 switches�
Menu item only visible if hysteresis function is selected ([ou1] = [H��])
FH2 / FL2 Upper / lower limit for the acceptable range within which OUT2 switches�
Menu item only visible if window function is selected ([ou1] = [F��])
EF
┘
Extended functions / opening of menu level 2
10.2.2 EF level (extended functions) [II]
rES Restore factory setting
CFG
┘
Open the submenu CFG (configuration)
ENV
┘
Open the submenu ENV (environment parameter)
SIM
┘
Open the submenu SIM (simulation)
