12.8 Output response in different operating states
OUT1 OUT2*
Initialisation OFF OFF
Normal operation
According to the level and
[ou1] setting
According to the level 4���20
mA
Fault
OFF for [FOU1] = [OFF]
ON for [FOU1] = [On]
< 3�6 mA at [FOU2] = [OFF]
> 21 mA at [FOU2] = [On]
* If the analogue function [ou2] = [I] has been selected�
If the switching function has been selected: see column OUT1
Additional information about the analogue output:
Full signal: With [ou2] = [I]: 20���20�5 mA
With [ou2] = [InEG]: 4���3�8 mA
Empty signal: With [ou2] = [I]: 4���3�8 mA
With [ou2] = [InEG]: 20���20�5 mA
13 Technical data
Technical data and scale drawing at www�ifm�com
13.1 Setting ranges
[LEnG] mm inches
Setting range 150���2000 6�0���78�8
Step increment 5 0�2
The setting ranges for the switching limits [SPx], [rPx], [FHx], [FLx] depend on the
rod length (L)� In general the following applies:
mm inches
min max min max
[SPx] / [FHx] 15 (35) L - 30 0�6 (1�4) L - 1�2
[rPx] / [FLx] 10 (30) L - 35 0�4 (1�2) L - 1�4
Step increment 1 0�05
Note: The values in brackets apply to the setting [MEdl] = [LOW) (→ 11.2.3)
• [rPx] / [FLx] is always smaller than [SPx] / [FHx]� If [SPx] / [FHx] is shifted, [rPx] / [FLx] also
shifts provided that the lower end of the setting range is not reached� Always set [SPx] /
[FHx] first, then [rPx] / [FLx]�
