10.2.3 CFG level (configuration) [III]
ou1 Output configuration for OUT1:
• Switching signal for level limit value� Hysteresis or window function,
normally closed or normally open
ou2 Output configuration for OUT2:
• Analogue signal for current level, 4…20 mA or 20…4 mA
or
• Switching signal for level limit value� Hysteresis or window function,
normally closed or normally open
dS1 Switch-on delay for OUT1
dr1 Switch-off delay for OUT1
dS2*
)
Switch-on delay for OUT2
dr2*
)
Switch-off delay for OUT2
uni Selection of the unit of measurement on the sensor display (mm or inch)
P-n Output polarity for the switching outputs (pnp or npn)
FOU1 Response of OUT1 in case of a fault
FOU2 Response of OUT2 in case of a fault
SELd Selection of the type of indication
dAP Damping of the measured signal (mean filter)
dFo Delay time for the outputs to pass into the state defined with [FOUx]; only
effective in case of a fault�
*
)
Menu item only visible with hysteresis or window function ([ou2] = [H��]) or [°F��])�
10.2.4 ENV level (environment) [IV]
Prob* Input of the type of probe (single probe or coaxial probe)
LEnG Input of the rod length
MEdI Medium selection
* Menu item only visible if [MEdI] = [HIGH] or [MId]�
10.2.5 SIM level (simulation) [V]
S�LvL Simulation of a level / an error state
S�Tim Simulation duration 1���60 min
S�On Simulation start/stop
