Sub-menu external characteristic vibration values EV1) and EV2) with respective
configuration
ESP1 Switch point pre-alarm
If the switch point is exceeded,
- OU1 switches, if it is digital
- the yellow LED "OU1" lights
- the measured value display changes to yellow
ESP2 Switch point main alarm
If the switch point is exceeded,
- OU2 switches
- the red LED "OU2" lights
- the measured value display changes to red
AUER Averaging → chapter 6.5
Sub-menu external characteristic vibration values EP1) and EP2) with respective
configuration
ESP1 Switch point pre-alarm
If the switch point is exceeded,
- OU1 switches, if it is digital
- the yellow LED "OU1" lights
- the measured value display changes to yellow
Eh1 Hysteresis pre-alarm
Absolute distance between set and reset point
ESP2 Switch point main alarm
If the switch point is exceeded,
- OU2 switches
- the red LED "OU2" lights
- the measured value display changes to red
Eh2 Hysteresis main alarm
Absolute distance between set and reset point
Sub-menu external input as analogue current input
EASP Scaling of external sensor for the process value,
initial value of the measuring range at 4 mA
EAEP Scaling of external sensor for the process value,
final value of the measuring range at 20 mA
Sub-menu outputs
ou1 Switching logic OU1 (OU1 = digital)
NC, NO (normally closed, normally open)
