Chapter 1 Cobalt Overview
Opening the Main Door
Use caution to keep hands clear of pinch points when closing doors.
Care must be taken when closing the door when the terminal is not secured. Closing
force should be applied downward rather than outward towards the operator.
1. Set the Main Door lock to the unlocked position.
2. Move the Main Door latch to the left.
Figure 1-8 Main Door Latch and Lock
3. While holding the edge of the door, lift the door upwards (A). The bottom portion of the
button panel remains in place (B).
Figure 1-9 Main Door Open
When closing the door, ensure the lock is unlocked and the latch is to the left.
18 Cobalt™ 27
