Chapter 2 Hardware
UBA Bill Validator Removal
The validator unit and stacker can be removed from the chassis of the bill validator.
Follow these steps to remove the validator unit and stacker:
1. Turn off the terminal.
2. Press down on the validator unit latch and slide the validator unit forward to remove it from
the chassis.
Figure 2-54 UBA Validator Unit Removal
3. Pull the stacker box handle to remove the stacker box.
Figure 2-55 UBA Stacker Box Removal
68 Cobalt™ 27
