Chapter 2 Hardware
Power Supply
This component contains high voltage. Always power off the gaming machine and
unplug the power cord prior to servicing.
The terminal has one (1) 750watt power supply to provide power for the machine’s DC-powered
components.
Features:
l Connection to Brain Box and Cabinet Controller board
l Auto switching 120-240 VAC
l +3.3VDC / +5VDC / +5VDC Unswitched / +12VDC / +24VDC / -12VDC
l Power supply wire harness separate from main wire harness
Figure 2-8 Power Supply
Cobalt™ 27 33
