Player Panel
The player panel consists of the multiple components.
Figure 2-19 Static Button Panel
Figure 2-20 Player Panel Components (Door Open View)
Label Description
1 Speakers
2
Optional Cashless Components (SMIB Module / Card Reader).
Refer to Cashless System Components on page 58 for more information.
3 USB Charging Port
4 Printer Bezel
5 Cashout Button
6 Service Button - Not used in this configuration
7 Bill Validator Bezel
8 Button Panel
