Chapter 2 Hardware
Nanoptix PayCheck 4™ Printer
The Nanoptix PayCheck 4 printer is a thermal printer that has a jam-resistant bezel, allows for quick
drop in replacement, and has easy access to the paper path. The Nanoptix printer is connected to
Cabinet Controller Board through a USB port at the back of the printer.
Figure 2-56 Nanoptix PayCheck 4 Printer
Nanoptix PayCheck 4 Printer Components
Figure 2-57 Nanoptix PayCheck 4 Printer
Number Feature Number Feature
1 Paper Tray 3 Release Lever
2 Paper Loading Slot 4 Ticket Out Slot, Bezel
