Chapter 2 Hardware
AVP 4+ Brain Box
The following list details the features of the AVP 4.0+ Brain Box:
l AMD Merlin Falcon APU
l 16GB Memory (SODIMM) standard
l 32GB Memory (SODIMM) maximum
l GPU
o
Three Onboard mini-Display Port (mDP) video interfaces
o
AMD E9260 PCIe GPU (video card) with four mDP video interfaces available (onboard
mDP will be disabled)
l Two 1Gb Ethernet Ports
l Dedicated on-board Authentication Processor
o
Requires APR00004 or later
l Solid State Drive in M.2 format (expansion card) standard
The following images and tables describe the AVP 4.0+ interface and components:
Figure 2-12 AVP 4.0+ Brain Box Interface (Security Door Closed)
36 Cobalt™ 27
