Chapter 2 Hardware
Cashout Button
The player panel includes a mechanical Cashout button, connected to the Cabinet Controller Board.
l Cashout Button: Allows players to cash out funds from the terminal.
Button Panel
The button panel consists of 5 mechanical buttons.
Figure 2-25 Static Button Panel
Button Panel Connectors
All buttons are interconnected by harness to the Cabinet Controller Board.
Figure 2-26 Static Button Panel Connectors
Cobalt™ 27 47
