Chapter 2 Hardware
Cabinet Controller Board Connectors
LED Table
LED Color Indication LED Color Indication
DS1 Green Presence of +24VDC rail DS33 Yellow USB over-current detection
DS2 Green Presence of +12VDC rail DS34 Yellow USB over-current detection
DS3 Green Presence of +5V rail DS35 Yellow USB over-current detection
DS5 Green Presence of +1.2VDC rail. DS36 Yellow USB over-current detection
DS7 Green Presence of +5V Standby rail DS37 Yellow USB over-current detection
DS8 Green Telltale Battery Charge DS38 Yellow USB over-current detection
DS10 Green USB device enumerator DS39 Yellow USB over-current detection
DS11 Green USB device enumerator DS50 Yellow Drop Door
DS12 Green USB device enumerator DS51 Yellow Security Door
DS13 Green USB device enumerator DS52 Red RS232 transmit data
DS14 Green USB device enumerator DS54 Green RS232 receive data
DS15 Green USB device enumerator DS55 Red LPC1759 FAULT
DS16 Green USB device enumerator DS57 Green Presence of +2.5VDC rail
DS18 Green FPGA configure done DS58 Green LPC1759 processor OK
DS19 Yellow Main Door 1 DS59 Yellow LPC1759 USB device enumerator
DS20 Yellow Main Door 2 DS60 Green Presence of +3.3VDC rail
DS21 Yellow Front Door DS61 Red FPGA Error Indicator
DS23 Yellow Bill Door DS62 Yellow Meter Cover Indicator
DS28 Yellow Cash Box
DS31 Yellow W2G
DS32 Yellow Jackpot Reset
Cobalt™ 27 41
