DIELECTRIC WITHSTAND TEST MODE
Current Display
Auto Range
AC
Range 1:
0.000mA – 3.500mA
Resolution:
0.001mA
Range 2:
3.00 – 20.00 mA
Resolution:
0.01 mA
DC
Range 1:
0.0 A – 350.0 A
Resolution:
0.1 A
Range 2:
0.300 mA – 3.500 mA
Resolution:
0.001 mA
Range 3:
3.00 mA – 7.50 mA
Resolution:
0.01 mA
Accuracy:
All Ranges
 (2 of reading  2 counts)
DC Output Ripple
 5 Ripple RMS at 6 KV DC @ 7.5 mA, Resistive Load
Discharge Time
 200 ms
The maximum capacitive load vs output voltage :
0.20 F ---  1KV
0.10 F ---  2KV
0.06 F ---  3KV
0.050 F ---  4KV
0.040 F ---  5KV
0.015 F ---  6KV
AC Voltage Wave Form
Sine Wave, Crest Factor = 1.3 – 1.5
Output Frequency
Range:
50 or 60 Hz, User Selectable
Accuracy:
 0.1%
Output Voltage
Regulation
 (1  of output  5 volts)
from no load to full load and over input voltage range.
Dwell Timer
Range:
AC: 0, 0.3 – 999.9 sec (0 = Constant)
DC: 0, 0.4 – 999.9 sec (0 = Constant)
Resolution:
0.1 sec
Accuracy:
 (0.1% of reading + 0.05 sec)
Ramp Timer
Range:
Ramp-Up: 0.1 – 999.9 sec
Ramp-Down: AC 0.0 – 999.9 sec
DC 1.0 – 999.9 sec 0=OFF
Resolution:
0.1 sec
Accuracy:
 (0.1% of reading + 0.05 sec)
Ground Continuity
Current
DC 0.1 A  0.01A, fixed
Ground Continuity
Range:
0.0 - 1.50
Maximum Limit
Resolution:
0.01
Minimum Limit
Accuracy:
 (3% of setting + 0.02)
Ground Continuity
Range:
0.0 - 0.50
Auto Offset
Resolution:
0.01
Accuracy:
 (3% of setting + 0.02)
