Imada ZTS Series User Manual

page 17page 16
CATEGORY COMMAND DESCRIPTION RESPONSE NOTES
XAR[CR] Real Time Data Output Request
XFP[CR] +Peak and –Peak Data Output Request
Data Output XFF[CR] 1st Peak and 2nd Peak Data Output Request
XAg[CR] Continuous Data Output Request (10 data/sec)
XAG[CR] Continuous Data Output Request (2000 data/sec) USB connection only
XAS[CR] Stop Continuous Data Output R[CR]
±UUUU: High Setpoint
XCW Set High/Low Comparator R[CR] ±LLLL: Low Setpoint
Comparator (w/o decimal point)
XCRH[CR] Display > High Set
XCR High/Low Comparator Output Request XCRO[CR] High ≥ Display ≥ Low
XCRL[CR] Display < Low Setpoint
XCRE[CR] Overload
XDS0[CR] Real Time Display
Mode XDS1[CR] Switch Mode Peak Display
XDS2[CR] +Peak Display
XDS3[CR] –Peak Display
XFU0[CR] Unit0
XFU1[CR] Switch Unit Unit1
Unit XFU2[CR] Unit2
XFU[3~5][CR] Unit3 - 5 (Option)
XFC List of Measuring Unit Output Request 00 - 55: Unit Code for Unit 0 - 5
(See Unit Code Table)
XFT Set 1st and 2nd Peak Sensitivity XFT[bbbb][CR] bbbb: Peak Sense Drop Digits
Peak (w/o decimal point)
XFG0[CR] Peak Switch Function Select Real Time, +Peak, –Peak (Functions cycle)
XFG1[CR] Real Time, Peak (Functions toggle)
XFY[CR] Reset Peak
Reset XFZ[CR] Tare
XAZ[CR] Reset All (Peak and Tare)
XMM[CR] Save Data in Memory R[CR]
Memory XMR[CR] Download All Memory Data Request See Memory Data Output Format
XMC[CR] Clear All Memory R[CR]
XME[CR] Clear Last Memory R[CR]
Counter XCN[CR] +NG Counter data output request XCN[nnnn][CR] nnnn: Number of +NG
XCC[CR] Clear +NG Counter R[CR]
Power XQT[CR] Turn off Power R[CR]
Other Invalid command E[CR]
4.Command Table (RS232C & USB communication)
Data Output
See Data Output Format
XCW[±UUUU][±LLLL][CR] Set High/Low Setpoints
XCR[CR] High/Low Setpoint Output Request
Switch Mode
Switch Unit
XFT[bbbb][CR] Set 1st and 2nd Peak Sensitivity
R[CR]
Peak Switch Function Select
R[CR]
R[CR] (See XFC command to get unit info.)
R[CR]
R[CR]
R[CR]
Setpoints
Mode
Unit
Peak
Reset
Memory
Counter
XFC[CR] List of Measuring Unit Output Request
XFC[00][11][22][33][44][55][CR] 00 - 55: Unit Code for Unit 0 - 5 (See Unit Code Table)

Imada ZTS Series Specifications

General

Display	LCD
Sampling Rate	2000 Hz
Measurement Units	N, kgf, lbf
Data Output	USB, RS-232
Power Supply	AC adapter or battery
Battery Life	Approx. 8 hours
Operating Temperature	0°C to 40°C
Storage Temperature	-10°C to 50°C (14°F to 122°F)
Accuracy	+/- 0.2% F.S.
